Layers that resolve before the bolt turns.
Structural and MEP shop drawing preparation, coordination clash detection, and authority submission packages for Dubai Municipality, DDA, and Trakhees — pre-approved before site mobilisation.
Coordinate my package arrow_forwardOur Methodology
Coordination Before the Site Pays for It
Shop drawing clashes discovered on site are not engineering problems — they are coordination gaps. PKAS reviews and coordinates drawings before mobilisation, eliminating the RFI cycles and delay claims that follow unresolved conflicts.
Shop Drawing Preparation
Structural and MEP shop drawings prepared from IFC design drawings, incorporating contractor method, site conditions, and local standards.
MEP Coordination
Mechanical, electrical, plumbing, and fire protection systems coordinated on a unified drawing set — clash-free before site issue.
Authority Submissions
Drawing packages prepared for Dubai Municipality, DDA, and Trakhees submission — formatted, indexed, and accompanied by calculation packs where required.
As-Built Drawings
As-built record drawings captured progressively throughout construction and finalised at practical completion for O&M handover.
Why It Matters
The Cost of Uncoordinated Drawings
A typical uncoordinated MEP set on a mid-size commercial building contains 150–200 coordination clashes. Each one resolved on site costs 5–20x what pre-approval would have cost.
Every unresolved drawing query raised as an RFI on site adds 1–3 days to the programme. PKAS pre-approval eliminates most of them before they start.
A drawing package rejected by Dubai Municipality or DDA means weeks of revision and resubmission. PKAS prepares submissions to the standard authorities expect.
What's Included
Every Engagement Covers
Shop Drawing Set
Complete shop drawing package for structural, MEP, and architectural trades.
Clash Detection Report
Pre-coordination clash report with resolution log before drawings are issued for construction.
Authority Submission Package
Formatted submission for Dubai Municipality, DDA, or Trakhees with supporting calculations.
As-Built Record Set
Final as-built drawings captured progressively and delivered at practical completion.
Also Available
Other PKAS Services
Ready to Start?
Let's discuss your requirements.
Free initial consultation. Mobilisation within 48 hours of instruction.
